WB13K21 Gas Range Oven Igniter for GE Samsung Hotpoint

WB13K21 Gas Range Oven Igniter

Key Features

• Flat-style gas oven igniter
• Ignites gas for the main oven burner
• Includes mounting bracket
• Features an 8-inch wire lead with a 2-prong plug
• Supplied with two porcelain wire nut connectors for splicing

Replaces / Cross-Reference Part Numbers

• WB13K21
• DS020KX
• AP2020569
• 2494
• AH231280
• EA231280
• PS231280

Compatibility & Fitment

• Designed for use in many gas-powered ranges and ovens.
• Direct fit for numerous GE Appliances models.
• Compatible with select models from brands including Kenmore, Hotpoint, and Samsung.
• Example of a compatible model: GE JGB280DEN1BB.

When to Replace

• Oven fails to heat or does not light.
• Igniter glows, but the burner does not ignite.
• Delayed ignition or inconsistent flame.
• Visible gas smell without ignition after the preheat cycle begins.

Installation Tips

• Disconnect power and shut off the gas supply to the appliance before installation.
• The igniter element is fragile. Handle with care and avoid touching the dark gray element with bare hands.
• Use the included porcelain wire nuts to splice wires if the original plug is different.
• Ensure the igniter is securely mounted and positioned correctly near the burner.
