W10189703 Refrigerator Evaporator Fan Motor for Whirlpool Maytag Kenmore Refrigerators

W10189703 Refrigerator Evaporator Fan Motor

Key Features

• Circulates air over evaporator coils to cool refrigerator and freezer compartments
• Voltage: 115V
• Frequency: 60Hz
• Current: 0.135A
• Speed: 3000 RPM

Replaces / Cross-Reference Part Numbers

• WPW10189703
• AP6016598
• PS11749890
• 2219647
• W10208121
• 2188848
• 10449505
• 10449506
• WPW10189703VP
• 8170682

Compatibility & Fitment

Direct replacement for various refrigerator models from brands including:

• Whirlpool
• Kenmore
• Maytag
• Amana
• Roper

When to Replace

Consider replacement if you observe the following symptoms:

• Refrigerator compartment is warm while the freezer remains cold
• Unusual noises (whirring, grinding, or rattling) from the freezer area
• The fan motor does not run when the compressor is on
• Inadequate cooling or temperature fluctuations

Installation Tips

• Disconnect the refrigerator from its power source before starting the installation.
• The evaporator fan is typically located behind an access panel inside the freezer compartment.
• Have towels ready to manage any frost or ice melt during the process.
• Note the orientation and connection of wires before removing the old motor.
