0130F00010 Furnace Flame Sensor Replacement - For Goodman Amana Furnaces

0130F00010 Furnace Flame Sensor

Key Features

• Detects flame in Hot Surface Ignition (HSI) systems for safe furnace operation.
• Constructed with a metal sensing rod and an alumina ceramic insulator.
• Designed as a direct-fit replacement for specified furnace models.
• Mounts to the burner assembly.

Replaces / Cross-Reference Part Numbers

• 0130F00010
• B1172606
• B11726-06
• 20488501
• TJFLS013
• 2645136
• AP4513976
• AP6326767
• L38035
• ACS90453BXA

Compatibility & Fitment

• For use in specific furnace models from Goodman, Amana, Daikin, and Janitrol.
• Confirm fitment by referencing your equipment's service manual or the original part number.

When to Replace

• Furnace burners ignite but shut off after a few seconds.
• Main burners fail to remain lit after the ignition sequence.
• Visible carbon buildup, corrosion, or cracking on the sensor rod or ceramic insulator.
• Control board displays a fault code related to flame sense failure.

Installation Tips

• Disconnect all electrical power and shut off the gas supply to the furnace before installation.
• The sensor is typically secured by a single screw on the burner bracket.
• Position the sensor rod so it will be directly in the path of the burner flame.
• Handle the new sensor carefully and avoid touching the ceramic insulator with bare hands.
